Description
This Maxim® WT welded hydraulic cylinder, rated at 3000 PSI, has a 3 in. bore X 4 in. stroke. The Maxim WT is Bailey’s best value cylinder with cross-tube mounting. Designed for demanding double-acting applications this welded cylinder exceeds the highest standards and is built to ensure maximum reliability and performance. With a compact design WT cylinders are also ideal for mobile applications where space is at a premium.
The Maxim WT is packed with these features:
- Engineered with a robust ductile iron piston for unparalleled durability in demanding environments.
- Enhanced security and stability ensured by the Grade 8 zinc-plated lock nut.
- Reliable sealing mechanism featuring a nitrile O-ring with hytrel backup for consistent, leak-free performance.
- Exceptional rod-sealing capabilities provided by the PolyPak design, incorporating a polyurethane U-cup with a Nitrile O-ring expander.
- Sturdy steel cross tube mounts serve as reliable end mounts, ensuring stability and facilitating effortless installation for hydraulic systems.
- Uncompromising seal integrity guaranteed by the piston's O-ring for its inner diameter and Hallite 755 piston seal with wear rings for the outer diameter.
- Finished in a sleek black coating, not only enhancing its aesthetics but also offering protection against corrosion for long-lasting performance.
Specifications
Weight:
18.52 LBS
Bore:
3 in
Stroke:
4 in
PSI:
3000
Rod Dia.:
1.5 in
Pin Dia. :
1 in
Retracted:
12 in
Extended:
16 in
Port Size:
SAE 8
Column Load:
21200 lbs
